Canopea Wind
Suspended acoustic island in solid wood
Characteristics
|
Panel dimensions |
1450 mm and 800 mm |
|---|---|
|
Slat cross-section |
20 mm (face) x 68 mm (height) |
|
Slat spacing |
72 mm |
|
Center distance of slats |
92 mm |
|
Black rear counter-slats |
34 x 40 mm |
|
Total thickness |
274 mm |
|
Wood |
Pine, oak, beech |
|
Pine weight |
between 15.80 and 16.20 kg |
|
Oak weight |
between 16.80 and 17.20 kg |
|
Beech weight |
between 17.50 and 17.80 kg |
Acoustic performance
The various acoustic absorption data were tested in accordance with the recommendations of ISO 354.
CANOPEA WIND + PET 5 mm
Suspended 30 cm from substrate
Weighted index: αw = 0.50 (MH)
CANOPEA WIND + Sheep’s wool 5 mm
Suspended 30 cm from support
Weighted index: αw = 0.55 (MH)
Finish / Reaction to fire (according to NF P 92-501)
Possibility of M1 fireproofing.
Fitting system
Kit of 4 hangers
(rope block + 2m diameter 1mm rope + 180° sphere top mount)
Wood and finishes
Wood
Slat finishes
Varnished finish
Wax color finishes
Other colors on request
Clear varnish required for sensitive environments
Counter-slat finish
Wax color finishes
